This item is a M12 x 1.25mm Standard Pitch Right Hand Thread, Male to Female High Performance, High Misalignment Angle Ball Joint - ideal for use in all types of motorsport or Kit Car type applications such as linkages and Anti Roll Bar Links etc

Supplied with a fine thread pitch (1.25mm) M12 internal and External thread , this ball joint is rated to a Radial Static Load of  37.5 KN , these Ball Points are made from heat treated carbon Steel  which is protective coated for corrosion resistance.

Male thread to opposite end of rod - 58mm

Female thread to opposite end of rod - 66.8mm

Width at widest point - 33.1mm

Length of male thread - 17.4mm

They also are zero maintenance as they come pre-lubricated.

Ball

• Bearing Steel
• Hard Chrome Plated
• Hardened

  Body

• Carbon Steel
• Heat Treated
• Protective Coated for Corrosion Resistance

Exclusive Features

• Maintenance Free.
• Ideal for replacing existing Ball joints

Radial Static Load Specification

• 37.5 KN

Angular Displacement Specification

• +/- 15 degrees.

  Perfect for all general forms of Motorsports.
