Brake/Clutch  Master Cylinder , 0.70" (18 mm) Heavy Duty Level 2

Brake King products are manufactured under strict quality control procedures & supplied with a 1 year warranty. These Master Cylinders are universal fit and can be used as  brake or clutch Master Cylinders.

This Girling/Castrol style universal type brakefluid reservoir we offer in our store can be used in conjunction with these brake or clutch master cylinders.

DESIGN

• Bore Size is 0.70" (18 mm)
• Pushrod Thread is M8x1.25mm standard thread
• Supplied with the M8x1.25mm Female Rod end for Brake Pedal attachment.
• Supplied with both copper Brake Pipe ends for quick attachment.
• Inlet is 7/16" UNF thread -suitable for the Master Brake/Clutch fluid reservoir we offer in our store here also (see the LEVEL 3 option in our store)
• Outlet is 3/8"-24 UNF
• 2 1/4" (57mm) between the mounting points.
• Suitable for Hydraulic Handbrakes and Pedal Boxes -standard fitment size.

EXCLUSIVE FEATURES

• 1 year guarantee
• Free UK 1st class postage

WARNING

IT IS THE RESPONSIBILITY OF THE PERSON INSTALLING AND BRAKE COMPONENT OR KIT TO DETERMINE THE SUITABILITY OF THAT COMPONENT OR KIT FOR THAT PARTICULAR APPLICATION. IF YOU ARE NOT SURE HOW TO SAFELY USE THIS BRAKE COMPONENT OR KIT, YOU SHOULD NOT INSTALL OR USE IT. DO NOT ASSUME ANYTHING. IMPROPERLY INSTALLED OR MAINTAINED BRAKES ARE DANGEROUS. IF YOU ARE UNSURE, SEEK EXPERT PROFESSIONAL QUALIFIED HELP OR RETURN THIS ITEM TO US. YOU, OR THE PERSON WHO INSTALLS THIS PRODUCT, MUST KNOW HOW TO INSTALL OR PROPERLY USE THIS PRODUCT. IT IS NOT POSSIBLE TO OFFER TECHNICAL ASSISTANCE OVER THE PHONE TO UNDERSTAND OR FORESEE ALL THE ISSUES THAT MIGHT ARISE IN YOUR SPECIFIC INSTALLATION. RACING EQUIPMENT AND BRAKES MUST BE MAINTAINED AND SHOULD BE CHECKED REGULARLY FOR DAMAGE, WEAR OR FATIGUE.

Brake Kings Fluid Reservoir - Ideal for Motorsport and Road Going Applications.

To complement these reservoirs, we have a range of other products available in our online store.
